STMicroelectronics S2-LPQTR
- Part No.:
- S2-LPQTR
- Manufacturer:
- STMicroelectronics
- Category:
- RF Transceiver ICs
- Package:
- 24-VFQFN Exposed Pad
- Datasheet:
-
S2-LPQTR.pdf
- Description:
- IC RF TXRX ISM<1GHZ 24QFN
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
S2-LPQTR Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- STMicroelectronics
- Series:
- -
- Package/Case:
- 24-VFQFN Exposed Pad
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Programmable:
- Not Verified
- Type:
- TxRx Only
- RF Family/Standard:
- General ISM < 1GHz
- Protocol:
- SIGFOX™, Wireless M-Bus
- Modulation:
- 2GFSK, 4GFSK, ASK, OOK
- Frequency:
- -
- Data Rate (Max):
- 500kbps
- Power - Output:
- 10dBm
- Sensitivity:
- -130dBm
- Memory Size:
- -
- Serial Interfaces:
- SPI, UART
- GPIO:
- 4
- Voltage - Supply:
- 1.8V ~ 3.6V
- Current - Receiving:
- 8mA
- Current - Transmitting:
- 27mA
- Operating Temperature:
- -40°C ~ 85°C
- Grade:
- -
- Qualification:
- -
- Supplier Device Package:
- 24-QFN (4x4)
| Image |  |
|
 |
| Part Number | S2-LPQTR | S2-LPCBQTR | S2-LPTXQTR |
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Series | - | - | - |
| Package/Case | 24-VFQFN Exposed Pad | 24-VFQFN Exposed Pad | 24-VFQFN Exposed Pad |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Active | Discontinued at Digi-Key |
| Programmable | Not Verified | Not Verified | Not Verified |
| Type | TxRx Only | TxRx Only | TxRx + MCU |
| RF Family/Standard | General ISM < 1GHz | 802.15.4 | 802.15.4, General ISM < 1GHz |
| Protocol | SIGFOX™, Wireless M-Bus | SIGFOX™ | SIGFOX™, Wireless M-Bus |
| Modulation | 2GFSK, 4GFSK, ASK, OOK | 2FSK, 2GFSK, 4FSK, 4GFSK, ASK, OOK | 2FSK, 4FSK, 2GFSK, 4GFSK, ASK, OOK |
| Frequency | - | 452MHz ~ 527MHz, 904MHz ~ 1055MHz | 413MHz ~ 479MHz, 826MHz ~ 958MHz |
| Data Rate (Max) | 500kbps | 500kbps | 500kbps |
| Power - Output | 10dBm | 14dBm | 16dBm |
| Sensitivity | -130dBm | -128dBm | - |
| Memory Size | - | - | - |
| Serial Interfaces | SPI, UART | SPI | SPI, UART |
| GPIO | 4 | 4 | 4 |
| Voltage - Supply | 1.8V ~ 3.6V | 1.8V ~ 3.6V | 1.8V ~ 3.6V |
| Current - Receiving | 8mA | 8.6mA | - |
| Current - Transmitting | 27mA | 20.6mA | 11.5mA ~ 32mA |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Grade | - | - | - |
| Qualification | - | - | - |
| Supplier Device Package | 24-QFN (4x4) | 24-QFN (4x4) | 24-QFN (4x4) |
