CEL PS7360-1A-V-A
- Part No.:
- PS7360-1A-V-A
- Manufacturer:
- CEL
- Category:
- Solid State Relays (SSR)
- Package:
- 6-DIP (0.300", 7.62mm)
- Datasheet:
-
PS7360-1A-V-A.pdf
- Description:
- SSR RELAY SPST-NO 90MA 0-600V
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
PS7360-1A-V-A Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- CEL
- Series:
- PS, OCMOS
- Packaging:
- Tube
- Product Status:
- Obsolete
- Mounting Type:
- Through Hole
- Circuit:
- SPST-NO (1 Form A)
- Output Type:
- AC, DC
- Voltage - Input:
- 1.2VDC
- Voltage - Load:
- 0 V ~ 600 V
- Load Current:
- 90 mA
- On-State Resistance (Max):
- 50 Ohms
- Termination Style:
- PC Pin
- Operating Temperature:
- -40°C ~ 85°C
- Supplier Device Package:
- 6-DIP
- Approval Agency:
- BSI, CSA, DEMKO, DIN, FIMKO, NEMKO, SEMKO, UL
- Grade:
- -
- Qualification:
- -
| Image |  |
 |
|
 |
|
| Part Number | PS7360-1A | PS7360L-1A | PS7360L-1A-A | PS7360-1A-A | PS7360L-1A-E3-A |
| Manufacturer | CEL | CEL | CEL | CEL | CEL |
| Series | PS, OCMOS | PS, OCMOS | PS, OCMOS | PS, OCMOS | PS, OCMOS |
| Packaging | Tube | Tube | Tube | Tube | Tape & Reel (TR) |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Mounting Type | Through Hole | Surface Mount | Surface Mount | Through Hole | Surface Mount |
| Circuit | SPST-NO (1 Form A) | SPST-NO (1 Form A) | SPST-NO (1 Form A) | SPST-NO (1 Form A) | SPST-NO (1 Form A) |
| Output Type | AC, DC | AC, DC | AC, DC | AC, DC | AC, DC |
| Voltage - Input | 1.2VDC | 1.2VDC | 1.2VDC | 1.2VDC | 1.2VDC |
| Voltage - Load | 0 V ~ 600 V | 0 V ~ 600 V | 0 V ~ 600 V | 0 V ~ 600 V | 0 V ~ 600 V |
| Load Current | 90 mA | 90 mA | 90 mA | 90 mA | 90 mA |
| On-State Resistance (Max) | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms |
| Termination Style | PC Pin | Gull Wing | Gull Wing | PC Pin | Gull Wing |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Supplier Device Package | 6-DIP | 6-DIP Gull Wing | 6-DIP Gull Wing | 6-DIP | 6-DIP Gull Wing |
| Approval Agency | BSI, CSA, DEMKO, DIN, FIMKO, NEMKO, SEMKO, UL | BSI, CSA, DEMKO, DIN, FIMKO, NEMKO, SEMKO, UL | BSI, CSA, DEMKO, DIN, FIMKO, NEMKO, SEMKO, UL | BSI, CSA, DEMKO, DIN, FIMKO, NEMKO, SEMKO, UL | BSI, CSA, DEMKO, DIN, FIMKO, NEMKO, SEMKO, UL |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
