Panasonic Electric Works HC4E-HTM-DC100V

Name: HC4E-HTM-DC100V
Brand: Panasonic Electric Works
SKU: HC4E-HTM-DC100V
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: HC4E-HTM-DC100V

Manufacturer:: Panasonic Electric Works

Category:: Signal Relays, Up to 2 Amps

Package:

Datasheet:: HC4E-HTM-DC100V.pdf

Description:: RELAY GEN PURPOSE 4PDT 2A 100V

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

HC4E-HTM-DC100V Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: Panasonic Electric Works

Series:: HC4E

Packaging:: Box

Product Status:: Obsolete

Mounting Type:: Chassis Mount

Coil Voltage:: 100VDC

Contact Form:: 4PDT (4 Form C)

Contact Rating (Current):: 2 A

Switching Voltage:: 250VAC - Max

Load - Max Switching:: 500VA

Coil Current:: 11 mA

Coil Type:: Non Latching

Features:: -

Termination Style:: Plug In, 14 Pin

Seal Rating:: Sealed - Fully

Coil Insulation:: -

Must Operate Voltage:: 80 VDC

Must Release Voltage:: 10 VDC

Operate Time:: 20 ms

Release Time:: 20 ms

Operating Temperature:: -50°C ~ 60°C

Contact Material:: Silver Alloy, Cadmium Free

Relay Type:: General Purpose

Grade:: -

Qualification:: -

Part Number	HC4E-H-AC115V	HC4E-H-AC12V	HC4E-H-AC240V	HC4E-H-AC24V	HC4E-H-AC48V
Manufacturer	Panasonic Electric Works	Panasonic Electric Works	Panasonic Electric Works	Panasonic Electric Works	Panasonic Electric Works
Series	HCE	HCE	HCE	HCE	HCE
Packaging	Bulk	Bulk	Bulk	Bulk	Bulk
Product Status	Obsolete	Obsolete	Obsolete	Obsolete	Obsolete
Mounting Type	Socketable	Socketable	Socketable	Socketable	Socketable
Coil Voltage	115VAC	12VAC	240VAC	24VAC	48VAC
Contact Form	4PDT (4 Form C)	4PDT (4 Form C)	4PDT (4 Form C)	4PDT (4 Form C)	4PDT (4 Form C)
Contact Rating (Current)	2 A	2 A	2 A	2 A	2 A
Switching Voltage	250VAC - Max	250VAC - Max	250VAC - Max	250VAC - Max	250VAC - Max
Load - Max Switching	500VA	500VA	500VA	500VA	500VA
Coil Current	10.4 mA	100 mA	5 mA	50 mA	25 mA
Coil Type	Non Latching	Non Latching	Non Latching	Non Latching	Non Latching
Features	-	-	-	-	-
Termination Style	Plug In	Plug In	Plug In	Plug In	Plug In
Seal Rating	-	-	-	-	-
Coil Insulation	-	-	-	-	-
Must Operate Voltage	92 VAC	9.6 VAC	192 VAC	19.2 VAC	38.4 VAC
Must Release Voltage	34.5 VAC	3.6 VAC	72 VAC	7.2 VAC	14.4 VAC
Operate Time	20 ms	20 ms	20 ms	20 ms	20 ms
Release Time	20 ms	20 ms	20 ms	20 ms	20 ms
Operating Temperature	-40°C ~ 60°C	-40°C ~ 60°C	-40°C ~ 60°C	-40°C ~ 60°C	-40°C ~ 60°C
Contact Material	Silver Nickel (AgNi), Gold (Au)	Silver Nickel (AgNi), Gold (Au)	Silver Nickel (AgNi), Gold (Au)	Silver Nickel (AgNi), Gold (Au)	Silver Nickel (AgNi), Gold (Au)
Relay Type	General Purpose	General Purpose	General Purpose	General Purpose	General Purpose
Grade	-	-	-	-	-
Qualification	-	-	-	-	-
