AUO G240UAN01.0

Name: G240UAN01.0
Brand: AUO
SKU: G240UAN01.0
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: G240UAN01.0

Manufacturer:: AUO

Category:: TFT-LCD Panel

Package:

Description:: AUO 24" IPS LCM 1920×1200 900nits WLED LVDS 51pins

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

Product Details

G240UAN01.0 Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: AUO

Panel Size:: 24"

TNVAIPS:: IPS

Resolution:: 1920×1200

CR:: 1900/2/10 16:01:00

Viewing Angle:: 89/89/89/89

Colors:: 1.07B

Outline Size:: 546.4(W)×352(H) ×18.6(D) mm

Treatment:

Brightness:: 900 cd/m² (Typ.)

Contrast Ratio:

View Direction:

Viewing Angle:: 89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)

Response Time:

Best View on:: Symmetry

Work Mode:

Glass Thickness:

Transmissivity:

Color Depth:: 1.07B 78% NTSC

Mass:: 2.50Kgs (Typ.)

Used for:

Touch Screen:

Refresh Rate:: 60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)

Part Number	G240UAN01.0	G240UAN01.1	G240UAN01.3	G240UAN01.2
Manufacturer	AUO	AUO	AUO	AUO
Panel Size	24"	24"	24"	24"
TNVAIPS	IPS	IPS	IPS	IPS
Resolution	1920×1200	1920×1200	1920×1200	1920×1200
CR	1900/2/10 16:01:00	1900/2/10 16:01:00	1900/2/25 6:01:00	1900/3/15 0:01:00
Viewing Angle	89/89/89/89	89/89/89/89	89/89/89/89	89/89/89/89
Colors	1.07B	1.07B	16.7M	1.07B
Outline Size	546.4(W)×352(H) ×18.6(D) mm	546.4(W)×352(H) ×18.6(D) mm	546.4(W)×352(H)×13.85(D) mm	546.4(W)×352(H) ×17.7(D) mm
Treatment		Antiglare		Antiglare
Brightness	900 cd/m² (Typ.)	850 cd/m² (Typ.)	410 cd/m² (Typ.)	400 cd/m² (Typ.)
Contrast Ratio		1000:1 (Typ.) (TM)		1800:1 (Typ.) (TM)
View Direction
Viewing Angle	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10)
Response Time		14 (Typ.)(Tr+Td)		12 (Typ.)(Tr+Td)
Best View on	Symmetry	Symmetry	Symmetry	Symmetry
Work Mode		AHVA, Normally Black, Transmissive		AHVA, Normally Black, Transmissive
Glass Thickness
Transmissivity
Color Depth	1.07B 78% NTSC	1.07B 88% NTSC	16.7M 99% Adobe RGB	1.07B 100% Adobe RGB
Mass	2.50Kgs (Typ.)	2.50Kgs (Typ.)	2.62Kgs (Typ)	2.50Kgs (Typ.)
Used for		Industrial; Medical Imaging; Outdoor High Brightness
Touch Screen		Without		Without
Refresh Rate	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz
