Sumida America Components Inc. ESMIT-4180/A
- Part No.:
- ESMIT-4180/A
- Manufacturer:
- Sumida America Components Inc.
- Category:
- Pulse Transformers
- Package:
- Datasheet:
-
ESMIT-4180/A.pdf
- Description:
- XFMR MODEM SMD
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
ESMIT-4180/A Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Sumida America Components Inc.
- Series:
- CBM
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Transformer Type:
- Data/Voice Coupling
- Inductance:
- 120µH
- ET (Volt-Time):
- -
- Turns Ratio - Primary:Secondary:
- 1:1
- Mounting Type:
- Surface Mount
- Size / Dimension:
- 0.205" L x 0.280" W (5.20mm x 7.10mm)
- Height - Seated (Max):
- 0.138" (3.50mm)
- Operating Temperature:
- -20°C ~ 105°C
- Grade:
- -
- Qualification:
- -
| Image |  |
 |
 |
|
| Part Number | ESMIT-4180/A | ESMIT-4164 | ESMIT-4154 | ESMIT-4155 |
| Manufacturer | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. |
| Series | CBM | CBM | * | * |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Active | Active | Active |
| Transformer Type | Data/Voice Coupling | Data/Voice Coupling | - | - |
| Inductance | 120µH | 30µH | - | - |
| ET (Volt-Time) | - | - | - | - |
| Turns Ratio - Primary:Secondary | 1:1 | 1:1.67 | - | - |
| Mounting Type | Surface Mount | Surface Mount | - | - |
| Size / Dimension | 0.205" L x 0.280" W (5.20mm x 7.10mm) | 0.179" L x 0.280" W (4.55mm x 7.10mm) | - | - |
| Height - Seated (Max) | 0.138" (3.50mm) | 0.078" (1.98mm) | - | - |
| Operating Temperature | -20°C ~ 105°C | - | - | - |
| Grade | - | - | - | - |
| Qualification | - | - | - | - |
