Infineon Technologies CYBT-343026-01
- Part No.:
- CYBT-343026-01
- Manufacturer:
- Infineon Technologies
- Category:
- RF Transceiver Modules and Modems
- Package:
- 24-SMD Module
- Datasheet:
-
CYBT-343026-01.pdf
- Description:
- RF TXRX MOD BT TH SMD
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
CYBT-343026-01 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Infineon Technologies
- Series:
- EZ-BT™ WICED®
- Package/Case:
- 24-SMD Module
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Programmable:
- Not Verified
- RF Family/Standard:
- Bluetooth
- Protocol:
- Bluetooth v4.2
- Modulation:
- 8DPSK, DQPSK, GFSK
- Frequency:
- 2.402GHz ~ 2.48GHz
- Data Rate:
- 6Mbps
- Power - Output:
- 12dBm
- Sensitivity:
- -96.5dBm
- Serial Interfaces:
- I2C, I2S, PCM, SPI, UART
- Antenna Type:
- Integrated, Trace
- Utilized IC / Part:
- -
- Memory Size:
- 512kB Flash
- Voltage - Supply:
- 2.3V ~ 3.6V
- Current - Receiving:
- 26.4mA
- Current - Transmitting:
- 60.3mA
- Mounting Type:
- Surface Mount
- Operating Temperature:
- -30°C ~ 85°C (TA)
| Image |  |
 |
 |
|
|
| Part Number | CYBT-343026-01 | CYBT-483056-02 | CYBT-353027-02 | CYBT-253059-02 | CYBT-413061-02 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Series | EZ-BT™ WICED® | - | EZ-BT™ WICED® | - | EZ-BT™ WICED® |
| Package/Case | 24-SMD Module | - | 19-SMD Module | 35-SMD Module | 30-SMD Module |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Active | Active | Active | Active |
| Programmable | Not Verified | Not Verified | Not Verified | Not Verified | Not Verified |
| RF Family/Standard | Bluetooth | - | Bluetooth | Bluetooth | Bluetooth |
| Protocol | Bluetooth v4.2 | - | Bluetooth v5.0 | Bluetooth v5.0 | Bluetooth v5.0 + EDR |
| Modulation | 8DPSK, DQPSK, GFSK | - | 8DPSK, DQPSK, GFSK | GFSK | 8DPSK, DQPSK, GFSK |
| Frequency | 2.402GHz ~ 2.48GHz | - | 2.402GHz ~ 2.48GHz | 2.4GHz | 2.4GHz |
| Data Rate | 6Mbps | - | 6Mbps | 3Mbps | 3Mbps |
| Power - Output | 12dBm | - | 12dBm | 10.5dBm | 4dBm |
| Sensitivity | -96.5dBm | - | -96.5dBm | -95dBm | -95dBm |
| Serial Interfaces | I2C, I2S, PCM, SPI, UART | - | I2C, I2S, PCM, SPI, UART | GPIO, HCI, I2C, I2S, PCM, PWM, SPI, UART | ADC, GPIO, I2C, I2S, PCM, PDM, PWM, SPI, UART |
| Antenna Type | Integrated, Trace | - | Integrated, Trace | Integrated, Chip | Integrated, Chip |
| Utilized IC / Part | - | - | - | - | CYW20719 |
| Memory Size | 512kB Flash | - | 512kB Flash | 256kB Flash, 176kB RAM | 1MB Flash, 512kB RAM, 2MB ROM |
| Voltage - Supply | 2.3V ~ 3.6V | - | 2.3V ~ 3.6V | 2.6V ~ 3.3V | 1.76V ~ 3.63V |
| Current - Receiving | 26.4mA | - | 26.4mA | 5.9mA | 5.9mA |
| Current - Transmitting | 60.3mA | - | 60.3mA | 22mA | 5.6mA |
| Mounting Type | Surface Mount | - | Surface Mount | Surface Mount | Surface Mount |
| Operating Temperature | -30°C ~ 85°C (TA) | - | -30°C ~ 85°C (TA) | -30°C ~ 85°C | -30°C ~ 85°C |
