Vishay Semiconductor Opto Division CNY65-3064

Product attributes

Attribute value

Manufacturer:

Vishay Semiconductor Opto Division

Series:

-

Package/Case:

4-EDIP (0.300", 7.62mm)

Packaging:

Bulk

Product Status:

Obsolete

Number of Channels:

1

Voltage - Isolation:

1390VDC

Current Transfer Ratio (Min):

50% @ 10mA

Current Transfer Ratio (Max):

300% @ 10mA

Turn On / Turn Off Time (Typ):

5µs, 3µs

Rise / Fall Time (Typ):

2.4µs, 2.7µs

Input Type:

DC

Output Type:

Transistor

Voltage - Output (Max):

32V

Current - Output / Channel:

50mA

Voltage - Forward (Vf) (Typ):

1.25V

Current - DC Forward (If) (Max):

75 mA

Vce Saturation (Max):

300mV

Grade:

-

Qualification:

-

Operating Temperature:

-55°C ~ 85°C

Mounting Type:

Through Hole

Supplier Device Package:

4-DIP
