Microchip Technology ATA6831-PIQW
- Part No.:
- ATA6831-PIQW
- Manufacturer:
- Microchip Technology
- Category:
- Full Half-Bridge (H Bridge) Drivers
- Package:
- 18-VFQFN Exposed Pad
- Datasheet:
-
ATA6831-PIQW.pdf
- Description:
- IC HALF BRIDGE DRIVER 1A 18VQFN
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
ATA6831-PIQW Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Microchip Technology
- Series:
- -
- Package/Case:
- 18-VFQFN Exposed Pad
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Obsolete
- Output Configuration:
- Half Bridge (3)
- Applications:
- Bulbs, DC Motors, Resistors
- Interface:
- PWM, SPI
- Load Type:
- Inductive, Capacitive, Resistive
- Technology:
- -
- Rds On (Typ):
- 1.5Ohm
- Current - Output / Channel:
- 1A
- Current - Peak Output:
- 1.3A
- Voltage - Supply:
- 4.75V ~ 5.25V
- Voltage - Load:
- 7V ~ 40V
- Operating Temperature:
- -40°C ~ 150°C (TJ)
- Grade:
- -
- Qualification:
- -
- Features:
- -
- Fault Protection:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 18-VQFN (4x4)
| Image |  |
 |
|
|
|
| Part Number | ATA6831C-PIQW-1 | ATA6831-PISW | ATA6831-PIPW | ATA6831C-PIQW | ATA6831-PIQW |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| Series | - | - | - | - | - |
| Package/Case | 18-VFQFN Exposed Pad | 18-VFQFN Exposed Pad | 18-VFQFN Exposed Pad | 18-VFQFN Exposed Pad | 18-VFQFN Exposed Pad |
| Packaging | Tape & Reel (TR) | Tube | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Obsolete | Obsolete | Obsolete | Obsolete |
| Output Configuration | Half Bridge (3) | Half Bridge (3) | Half Bridge (3) | Half Bridge (3) | Half Bridge (3) |
| Applications | Bulbs, DC Motors, Resistors | Bulbs, DC Motors, Resistors | Bulbs, DC Motors, Resistors | Bulbs, DC Motors, Resistors | Bulbs, DC Motors, Resistors |
| Interface | PWM, SPI | PWM, SPI | PWM, SPI | PWM, SPI | PWM, SPI |
| Load Type | Inductive, Capacitive, Resistive | Inductive, Capacitive, Resistive | Inductive, Capacitive, Resistive | Inductive, Capacitive, Resistive | Inductive, Capacitive, Resistive |
| Technology | Power MOSFET | - | - | Power MOSFET | - |
| Rds On (Typ) | 800mOhm LS, 800mOhm HS | 1.5Ohm | 1.5Ohm | 800mOhm LS, 800mOhm HS | 1.5Ohm |
| Current - Output / Channel | 1A | 1A | 1A | 1A | 1A |
| Current - Peak Output | - | 1.3A | 1.3A | - | 1.3A |
| Voltage - Supply | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 4.75V ~ 5.25V |
| Voltage - Load | 5.6V ~ 40V | 7V ~ 40V | 7V ~ 40V | 5.6V ~ 40V | 7V ~ 40V |
| Operating Temperature | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
| Features | - | - | - | - | - |
| Fault Protection | Open Load Detect, Over Temperature, Short Circuit, UVLO | - | - | Open Load Detect, Over Temperature, Short Circuit, UVLO | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | 18-QFN (4x4) | 18-VQFN (4x4) | 18-VQFN (4x4) | 18-VQFN (4x4) | 18-VQFN (4x4) |
