Renesas Electronics Corporation AT25SF161B-SSHD-T
- Part No.:
- AT25SF161B-SSHD-T
- Manufacturer:
- Renesas Electronics Corporation
- Category:
- Memory
- Package:
- 8-SOIC (0.154", 3.90mm Width)
- Description:
- IC FLASH 16MBIT SPI/QUAD 8SOIC
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
AT25SF161B-SSHD-T Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Renesas Electronics Corporation
- Series:
- -
- Package/Case:
- 8-SOIC (0.154", 3.90mm Width)
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Programmable:
- Not Verified
- Memory Type:
- Non-Volatile
- Memory Format:
- FLASH
- Technology:
- FLASH - NOR
- Memory Size:
- 16Mbit
- Memory Organization:
- 2M x 8
- Memory Interface:
- SPI - Quad I/O
- Clock Frequency:
- 108 MHz
- Write Cycle Time - Word, Page:
- 50µs, 1.8ms
- Access Time:
- 7 ns
- Voltage - Supply:
- 2.5V ~ 3.6V
- Operating Temperature:
- -40°C ~ 85°C (TC)
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 8-SOIC
| Image | .jpg) |
|
 |
|
|
| Part Number | AT25SF161B-SSHD-T | AT25SF161B-SSHB-T | AT25SF161B-UUB-T | AT25SF161B-SSHB-B | AT25SF161B-SSHD-B |
| Manufacturer | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| Series | - | - | - | - | - |
| Package/Case | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 8-XFBGA, WLCSP | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tube | Tube |
| Product Status | Active | Active | Active | Active | Active |
| Programmable | Not Verified | Not Verified | Not Verified | Not Verified | Not Verified |
| Memory Type | Non-Volatile | Non-Volatile | Non-Volatile | Non-Volatile | Non-Volatile |
| Memory Format | FLASH | FLASH | FLASH | FLASH | FLASH |
| Technology | FLASH - NOR | FLASH - NOR | FLASH - NOR | FLASH - NOR | FLASH - NOR |
| Memory Size | 16Mbit | 16Mbit | 16Mbit | 16Mbit | 16Mbit |
| Memory Organization | 2M x 8 | 2M x 8 | 2M x 8 | 2M x 8 | 2M x 8 |
| Memory Interface | SPI - Quad I/O | SPI - Quad I/O | SPI - Quad I/O | SPI - Quad I/O | SPI - Quad I/O |
| Clock Frequency | 108 MHz | 108 MHz | 108 MHz | 108 MHz | 108 MHz |
| Write Cycle Time - Word, Page | 50µs, 1.8ms | 50µs, 2.4ms | 50µs, 2.4ms | 50µs, 2.4ms | 50µs, 1.8ms |
| Access Time | 7 ns | - | - | - | 7 ns |
| Voltage - Supply | 2.5V ~ 3.6V | 2.7V ~ 3.6V | 2.7V ~ 3.6V | 2.7V ~ 3.6V | 2.5V ~ 3.6V |
| Operating Temperature | -40°C ~ 85°C (TC) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TC) |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | 8-SOIC | 8-SOIC | 8-WLCSP (1.61x1.35) | 8-SOIC | 8-SOIC |
