Diodes Incorporated AP3031KTR-XG1
- Part No.:
- AP3031KTR-XG1
- Manufacturer:
- Diodes Incorporated
- Category:
- LED Drivers
- Package:
- SOT-23-6
- Description:
- IC LED DRVR RGLTR PWM TSOT23-6
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
AP3031KTR-XG1 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Diodes Incorporated
- Series:
- -
- Package/Case:
- SOT-23-6
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Obsolete
- Type:
- DC DC Regulator
- Topology:
- Step-Up (Boost)
- Internal Switch(s):
- Yes
- Number of Outputs:
- 1
- Voltage - Supply (Min):
- 2.7V
- Voltage - Supply (Max):
- 16V
- Voltage - Output:
- -
- Current - Output / Channel:
- 1.4A (Switch)
- Frequency:
- 1MHz
- Dimming:
- PWM
- Applications:
- Backlight
- Operating Temperature:
- -40°C ~ 85°C (TA)
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- SOT-23-6
| Image |  |
|
 |
| Part Number | AP3031KTR-G1 | AP3031KTR-AG1 | AP3031KTR-XG1 |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| Series | - | - | - |
| Package/Case | SOT-23-6 Thin, TSOT-23-6 | SOT-23-6 Thin, TSOT-23-6 | SOT-23-6 |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Obsolete | Obsolete |
| Type | DC DC Regulator | DC DC Regulator | DC DC Regulator |
| Topology | Step-Up (Boost) | Step-Up (Boost) | Step-Up (Boost) |
| Internal Switch(s) | Yes | Yes | Yes |
| Number of Outputs | 1 | 1 | 1 |
| Voltage - Supply (Min) | 2.7V | 2.7V | 2.7V |
| Voltage - Supply (Max) | 16V | 16V | 16V |
| Voltage - Output | - | - | - |
| Current - Output / Channel | 1.4A (Switch) | 1.4A (Switch) | 1.4A (Switch) |
| Frequency | 1MHz | 1MHz | 1MHz |
| Dimming | PWM | PWM | PWM |
| Applications | Backlight | Backlight | Backlight |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Grade | - | - | - |
| Qualification | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | TSOT-23-6 | TSOT-23-6 | SOT-23-6 |
