aimtec AMEL60-12S277HAVZ
- Part No.:
- AMEL60-12S277HAVZ
- Manufacturer:
- aimtec
- Category:
- AC DC Converters
- Package:
- 4-DIP Module
- Datasheet:
-
AMEL60-12S277HAVZ.pdf
- Description:
- AC/DC Converter 5V 60W
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
AMEL60-12S277HAVZ Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- aimtec
- Series:
- AMEL60-277HAVZ (60W)
- Package/Case:
- 4-DIP Module
- Packaging:
- Product Status:
- Obsolete
- Type:
- Enclosed
- Number of Outputs:
- 1
- Voltage - Input:
- 85 ~ 305VAC, 100 ~ 430VDC
- Voltage - Output 1:
- 12V
- Voltage - Output 2:
- -
- Voltage - Output 3:
- -
- Voltage - Output 4:
- -
- Current - Output (Max):
- 5A
- Power (Watts):
- -
- Applications:
- Industrial
- Features:
- -
- Operating Temperature:
- -40°C ~ 85°C
- Efficiency:
- 91%
- Mounting Type:
- Through Hole
- Size / Dimension:
- 2.75" L x 1.88" W x 1.06" H (69.9mm x 47.8mm x 26.9mm)
- Approval Agency:
- -
- Standard Number:
- -
| Image |  |
 |
 |
|
|
| Part Number | AMEL60-48SJZ | AMEL60-48S277HAVZ | AMEL60-24SJZ | AMEL60-15SJZ | AMEL60-24S277HAVZ |
| Manufacturer | aimtec | aimtec | aimtec | aimtec | aimtec |
| Series | AMEL60-JZ (60W) | AMEL60-277HAVZ (60W) | AMEL60-JZ (60W) | AMEL60-JZ (60W) | AMEL60-277HAVZ (60W) |
| Package/Case | 4-DIP Module | 4-DIP Module | 4-DIP Module | 4-DIP Module | 4-DIP Module |
| Packaging | Box | Tray | Box | Box | Tray |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Type | Enclosed | Enclosed | Enclosed | Enclosed | Enclosed |
| Number of Outputs | 1 | 1 | 1 | 1 | 1 |
| Voltage - Input | 85 ~ 264 VAC, 100 ~ 370 VDC | 85 ~ 305VAC, 100 ~ 430VDC | 85 ~ 264 VAC, 100 ~ 370 VDC | 85 ~ 264 VAC, 100 ~ 370 VDC | 85 ~ 305VAC, 100 ~ 430VDC |
| Voltage - Output 1 | 48V | 48V | 24V | 15V | 24V |
| Voltage - Output 2 | - | - | - | - | - |
| Voltage - Output 3 | - | - | - | - | - |
| Voltage - Output 4 | - | - | - | - | - |
| Current - Output (Max) | 1.25A | 1.25A | 2.5A | 4A | 2.5A |
| Power (Watts) | 60 W | - | 60 W | 60 W | - |
| Applications | ITE (Commercial) | Industrial | ITE (Commercial) | ITE (Commercial) | Industrial |
| Features | Universal Input | - | Universal Input | Universal Input | - |
| Operating Temperature | -40°C ~ 70°C (With Derating) | -40°C ~ 85°C | -40°C ~ 70°C (With Derating) | -40°C ~ 70°C (With Derating) | -40°C ~ 85°C |
| Efficiency | 90% | 91% | 89% | 88% | 90% |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Size / Dimension | 3.43" L x 2.05" W x 1.16" H (87.0mm x 52.0mm x 29.5mm) | 2.75" L x 1.88" W x 1.06" H (69.9mm x 47.8mm x 26.9mm) | 3.43" L x 2.05" W x 1.16" H (87.0mm x 52.0mm x 29.5mm) | 3.43" L x 2.05" W x 1.16" H (87.0mm x 52.0mm x 29.5mm) | 2.75" L x 1.88" W x 1.06" H (69.9mm x 47.8mm x 26.9mm) |
| Approval Agency | - | - | - | - | - |
| Standard Number | - | - | - | - | - |
