Broadcom Limited ACHS-7122-500E

Product attributes

Attribute value

Manufacturer:

Broadcom Limited

Series:

-

Package/Case:

8-SOIC (0.154", 3.90mm Width)

Packaging:

Tape & Reel (TR)

Product Status:

Active

For Measuring:

AC/DC

Sensor Type:

Hall Effect

Current - Sensing:

20A

Number of Channels:

-

Output:

Ratiometric, Voltage

Sensitivity:

100mV/A

Frequency:

80kHz

Linearity:

±0.18%

Accuracy:

-

Voltage - Supply:

4.5V ~ 5.5V

Response Time:

4µs

Current - Supply (Max):

15mA

Operating Temperature:

-40°C ~ 110°C

Grade:

-

Qualification:

-

Polarization:

Bidirectional

Mounting Type:

Surface Mount

Supplier Device Package:

8-SO
