Coto Technology 9081-05-40
- Part No.:
- 9081-05-40
- Manufacturer:
- Coto Technology
- Category:
- Reed Relays
- Package:
- Datasheet:
-
9081-05-40.pdf
- Description:
- RELAY REED SPST 500MA 5V
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
9081-05-40 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Coto Technology
- Series:
- 9000, Spartan
- Packaging:
- Bulk
- Product Status:
- Obsolete
- Mounting Type:
- Through Hole
- Coil Voltage:
- 5VDC
- Contact Form:
- SPST-NO (1 Form A)
- Contact Rating (Current):
- 500 mA
- Switching Voltage:
- 200VAC, 200VDC - Max
- Coil Current:
- 5 mA
- Coil Type:
- Non Latching
- Features:
- EMI Shielded
- Termination Style:
- PC Pin
- Seal Rating:
- -
- Must Operate Voltage:
- 3.75 VDC
- Must Release Voltage:
- 0.4 VDC
- Operate Time:
- 0.5 ms
- Release Time:
- 0.2 ms
- Operating Temperature:
- -20°C ~ 85°C
- Contact Material:
- -
| Image |  |
|
|
 |
 |
| Part Number | 9081-05-00 | 9081-12-00 | 9081-24-00 | 9081-05-10 | 9081-24-10 |
| Manufacturer | Coto Technology | Coto Technology | Coto Technology | Coto Technology | Coto Technology |
| Series | 9000, Spartan | 9000, Spartan | 9000, Spartan | 9000, Spartan | 9000, Spartan |
| Packaging | Bulk | Bulk | Bulk | Tube | Bulk |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Coil Voltage | 5VDC | 12VDC | 24VDC | 5VDC | 24VDC |
| Contact Form | SPST-NO (1 Form A) | SPST-NO (1 Form A) | SPST-NO (1 Form A) | SPST-NO (1 Form A) | SPST-NO (1 Form A) |
| Contact Rating (Current) | 500 mA | 500 mA | 500 mA | 500 mA | 500 mA |
| Switching Voltage | 200VAC, 200VDC - Max | 200VAC, 200VDC - Max | 200VAC, 200VDC - Max | 200VAC, 200VDC - Max | 200VAC, 200VDC - Max |
| Coil Current | 10 mA | 12 mA | 12 mA | 10 mA | 12 mA |
| Coil Type | Non Latching | Non Latching | Non Latching | Non Latching | Non Latching |
| Features | - | - | - | EMI Shielded | EMI Shielded |
| Termination Style | PC Pin | PC Pin | PC Pin | PC Pin | PC Pin |
| Seal Rating | - | - | - | - | - |
| Must Operate Voltage | 3.75 VDC | 9 VDC | 18 VDC | 3.75 VDC | 18 VDC |
| Must Release Voltage | 0.4 VDC | 1 VDC | 2 VDC | 0.4 VDC | 2 VDC |
| Operate Time | 0.5 ms | 0.5 ms | 0.5 ms | 0.5 ms | 0.5 ms |
| Release Time | 0.2 ms | 0.2 ms | 0.2 ms | 0.2 ms | 0.2 ms |
| Operating Temperature | -20°C ~ 85°C | -20°C ~ 85°C | -20°C ~ 85°C | -20°C ~ 85°C | -20°C ~ 85°C |
| Contact Material | - | - | - | - | - |
