iNRCORE, LLC 100B-1003XNL
- Part No.:
- 100B-1003XNL
- Manufacturer:
- iNRCORE, LLC
- Category:
- Pulse Transformers
- Package:
- Datasheet:
-
100B-1003XNL.pdf
- Description:
- XFMR MODULE 100BT SMG COM NPB
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
100B-1003XNL Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- iNRCORE, LLC
- Series:
- -
- Packaging:
- Tube
- Product Status:
- Active
- Transformer Type:
- LAN 10/100 Base-T
- Inductance:
- 350µH
- ET (Volt-Time):
- -
- Turns Ratio - Primary:Secondary:
- 1:1
- Mounting Type:
- Surface Mount
- Size / Dimension:
- 0.500" L x 0.265" W (12.70mm x 6.73mm)
- Height - Seated (Max):
- 0.245" (6.22mm)
- Operating Temperature:
- -55°C ~ 125°C
- Grade:
- -
- Qualification:
- -
| Image |  |
 |
 |
 |
 |
| Part Number | 100B-1003XT | 100B-1003X | 100B-1003XNL | 100B-1003FXNL | 100B-1003NL |
| Manufacturer | iNRCORE, LLC | iNRCORE, LLC | iNRCORE, LLC | iNRCORE, LLC | iNRCORE, LLC |
| Series | - | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tube | Tube | Bulk | Bulk |
| Product Status | Active | Active | Active | Active | Active |
| Transformer Type | LAN 10/100 Base-T | LAN 10/100 Base-T | LAN 10/100 Base-T | LAN 10/100 Base-T | LAN 10/100 Base-T |
| Inductance | 350µH | - | 350µH | 350µH | 350µH |
| ET (Volt-Time) | - | - | - | - | - |
| Turns Ratio - Primary:Secondary | 1:1 | 1CT:1CT | 1:1 | 1:1 | 1:1 |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Size / Dimension | 0.500" L x 0.265" W (12.70mm x 6.73mm) | 0.500" L x 0.265" W (12.70mm x 6.73mm) | 0.500" L x 0.265" W (12.70mm x 6.73mm) | 0.500" L x 0.265" W (12.70mm x 6.73mm) | 0.500" L x 0.265" W (12.70mm x 6.73mm) |
| Height - Seated (Max) | 0.245" (6.22mm) | 0.245" (6.22mm) | 0.245" (6.22mm) | 0.245" (6.22mm) | 0.245" (6.22mm) |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | - | - |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
