NXP USA Inc. OL2385AHN/001B0Y
- Part No.:
- OL2385AHN/001B0Y
- Manufacturer:
- NXP USA Inc.
- Category:
- RF Transceiver ICs
- Package:
- 48-VFQFN Exposed Pad
- Datasheet:
-
OL2385AHN/001B0Y.pdf
- Description:
- IC RF TXRX+MCU 48HVQFN
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
OL2385AHN/001B0Y Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- NXP USA Inc.
- Series:
- -
- Package/Case:
- 48-VFQFN Exposed Pad
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Programmable:
- Not Verified
- Type:
- TxRx + MCU
- RF Family/Standard:
- -
- Protocol:
- Sigfox, Wireless M-Bus, Zigbee®
- Modulation:
- ASK, FSK
- Frequency:
- 158MHz ~ 960MHz
- Data Rate (Max):
- 400kbps
- Power - Output:
- 14dBm
- Sensitivity:
- -124dBm
- Memory Size:
- -
- Serial Interfaces:
- SPI, UART
- GPIO:
- 12
- Voltage - Supply:
- 1.9V ~ 5.5V
- Current - Receiving:
- -
- Current - Transmitting:
- 29mA
- Operating Temperature:
- -40°C ~ 85°C
- Grade:
- -
- Qualification:
- -
- Supplier Device Package:
- 48-HVQFN (7x7)
| Image |  |
 |
|
|
 |
| Part Number | OL2385AHN/00100Y | OL2385AHN/001A0 | OL2385AHN/001A2Y | OL2385AHN/001A0Y | OL2385AHN/001C0Y |
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Series | - | * | - | - | - |
| Package/Case | 48-VFQFN Exposed Pad | - | 48-VFQFN Exposed Pad | 48-VFQFN Exposed Pad | 48-VFQFN Exposed Pad |
| Packaging | Tape & Reel (TR) | Bulk | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Obsolete | Active | Obsolete | Active |
| Programmable | Not Verified | Not Verified | - | Not Verified | Not Verified |
| Type | TxRx + MCU | - | TxRx + MCU | TxRx + MCU | TxRx + MCU |
| RF Family/Standard | - | - | 802.15.4 | - | - |
| Protocol | - | - | Sigfox, Wireless M-Bus, Zigbee® | - | Sigfox, Wireless M-Bus, Zigbee® |
| Modulation | ASK, FSK | - | 2-FSK, 4-FSK, ASK, FSK, GFSK, OOK | ASK, FSK | ASK, FSK |
| Frequency | - | - | 158MHz ~ 960MHz | - | 158MHz ~ 960MHz |
| Data Rate (Max) | - | - | 400kbps | - | 400kbps |
| Power - Output | 14dBm | - | 14dBm | 14dBm | 14dBm |
| Sensitivity | -124dBm | - | -123dBm | -124dBm | -124dBm |
| Memory Size | - | - | 7kB RAM | - | - |
| Serial Interfaces | SPI, UART | - | GPIO, SPI, UART, USART | SPI, UART | SPI, UART |
| GPIO | 12 | - | 12 | 12 | 12 |
| Voltage - Supply | 1.9V ~ 5.5V | - | 1.9V ~ 5.5V | 1.9V ~ 5.5V | 1.9V ~ 5.5V |
| Current - Receiving | - | - | 600nA ~ 11mA | - | - |
| Current - Transmitting | 29mA | - | 500µA ~ 33mA | 29mA | 29mA |
| Operating Temperature | -40°C ~ 85°C | - | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
| Supplier Device Package | 48-HVQFN (7x7) | - | 48-HVQFN (7x7) | 48-HVQFN (7x7) | 48-HVQFN (7x7) |
