TDK-Lambda PFE300S-28/T
- Part No.:
- PFE300S-28/T
- Manufacturer:
- TDK-Lambda
- Category:
- AC DC Converters
- Package:
- 11-DIP Module, Full Brick
- Datasheet:
-
PFE300S-28/T.pdf
- Description:
- AC/DC CONVERTER 28V 300W
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
PFE300S-28/T Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- TDK-Lambda
- Series:
- PFE300S (300W)
- Package/Case:
- 11-DIP Module, Full Brick
- Packaging:
- Bulk
- Product Status:
- Obsolete
- Type:
- Enclosed
- Number of Outputs:
- 1
- Voltage - Input:
- 85 ~ 265 VAC
- Voltage - Output 1:
- 28V
- Voltage - Output 2:
- -
- Voltage - Output 3:
- -
- Voltage - Output 4:
- -
- Current - Output (Max):
- 10.8A
- Power (Watts):
- 300 W
- Applications:
- ITE (Commercial)
- Features:
- Universal Input
- Operating Temperature:
- -40°C ~ 100°C
- Efficiency:
- 86%
- Mounting Type:
- Through Hole
- Size / Dimension:
- 4.60" L x 2.40" W x 0.50" H (116.8mm x 61.0mm x 12.7mm)
- Approval Agency:
- CE, cULus
- Standard Number:
- 60950-1
| Image |  |
|
|
 |
|
| Part Number | PFE300SA-28 | PFE300SA-28/T | PFE300SA-12 | PFE300S-12/T | PFE300SA-48 |
| Manufacturer | TDK-Lambda | TDK-Lambda | TDK-Lambda | TDK-Lambda | TDK-Lambda |
| Series | PFE300SA (300W) | PFE300SA (300W) | PFE300SA (300W) | PFE300S (300W) | PFE300SA (300W) |
| Package/Case | 11-DIP Module, Full Brick | 11-DIP Module, Full Brick | 11-DIP Module, Full Brick | 11-DIP Module, Full Brick | 11-DIP Module, Full Brick |
| Packaging | Bulk | Bulk | Bulk | Bulk | Bulk |
| Product Status | Active | Active | Active | Obsolete | Active |
| Type | Enclosed | Enclosed | Enclosed | Enclosed | Enclosed |
| Number of Outputs | 1 | 1 | 1 | 1 | 1 |
| Voltage - Input | 85 ~ 265 VAC | 85 ~ 265 VAC | 85 ~ 265 VAC | 85 ~ 265 VAC | 85 ~ 265 VAC |
| Voltage - Output 1 | 28V | 28V | 12V | 12V | 48V |
| Voltage - Output 2 | - | - | - | - | - |
| Voltage - Output 3 | - | - | - | - | - |
| Voltage - Output 4 | - | - | - | - | - |
| Current - Output (Max) | 10.8A | 10.8A | 25A | 25A | 6.3A |
| Power (Watts) | 302 W | 302 W | 300 W | 300 W | 302 W |
| Applications | ITE (Commercial) | ITE (Commercial) | ITE (Commercial) | ITE (Commercial) | ITE (Commercial) |
| Features | Remote On/Off, Universal Input | Remote On/Off, Universal Input | Remote On/Off, Universal Input | Universal Input | Remote On/Off, Universal Input |
| Operating Temperature | -40°C ~ 100°C (With Derating) | -40°C ~ 100°C (With Derating) | -40°C ~ 100°C (With Derating) | -40°C ~ 100°C | -40°C ~ 100°C (With Derating) |
| Efficiency | 89% | 89% | 85% | 86% | 90% |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Size / Dimension | 4.60" L x 2.40" W x 0.50" H (116.8mm x 61.0mm x 12.7mm) | 4.60" L x 2.40" W x 0.50" H (116.8mm x 61.0mm x 12.7mm) | 4.60" L x 2.40" W x 0.50" H (116.8mm x 61.0mm x 12.7mm) | 4.60" L x 2.40" W x 0.50" H (116.8mm x 61.0mm x 12.7mm) | 4.60" L x 2.40" W x 0.50" H (116.8mm x 61.0mm x 12.7mm) |
| Approval Agency | CE, CSA, UL | CE, CSA, UL | CE, CSA, UL | CE, cULus | CE, CSA, UL |
| Standard Number | 60950-1; 62368-1 | 60950-1; 62368-1 | 60950-1; 62368-1 | 60950-1 | 60950-1; 62368-1 |
